EEWV/ S/ 208R
Exit Light
Item Description:
Exit Light
| Model | : | EEWV/ S/ 208R |
| Type | : |
ALL WEATHER |
| Mode of Operation | : | SUSTAINED |
| Lamp | : | 2x 8W FLUORESCENT LAMP |
| Rated Duration | : | 2 HOURS (OTHER DURATION AVAILABLE) |
| Main Supply | : | 230V/ 50Hz (OTHER VOLT & Hz AVAILABLE |
| Power Consumption | : | 12VA |
| Battery | : | MAINTENANCE FREE HIGH TEMP. RATED NICKEL CADMIUM CELLS |
| Charger | : | FULLY AUTOMATIC CONSTANT CURRENT |
| Charge Monitor | : | RED LED 5mm Ø |
| Test Facility (Optional) |
: | PUSH OFF, TEST SWITCH FOR INDEPENDENT TESTING |
Safety Feature |
: |
LOW VOLT CUT-OFF TO PREVENT OVER-DISCHARGE OF BATTERY |
| Housing | : | INJECTION MOULDED FIRE RETARDANT POLYCARBONATE |
| Diffuser | : | FIRE RETARDANT MOULDED ACRYLIC |
| Legend | : | ISO GREEN, OTHER LEGEND OPTIONAL |
| Mounting | : | CEILING OR SEMI-RECESS |
| Cable Entry | : | 20mm Ø K/ O HOLE |
| Weight | : | 2Kg (GROSS) |
| Compliance | : | SISIR CP19, S.S, 263: PART 2, IEC 598-2-22 |
